產品的主要特點Productmain features

與分離電器構成的系統相比

具有控制與保護自配合的特性

CPS系列控制與保護開關電器集控制與保護功能與一體，相當于斷路器(熔斷器)+接觸器+熱繼電器+輔助電器。很好的解決了分離元件不能或很難解決的元件之間的保護與控制特性匹配問題，使保護與控制特性配合更完美合理(具有反時限、定時限和照時三段保護特性)。只要根據負載功率或電流即可正確選擇著單一產品，代替以往的包括自電源進線至負載端的各種電器，不需降容;大大減輕了設計人員的工作量。

具有無可比擬的運行可靠性和系統的連續運行性能

CPS在分?jǐn)喽搪冯娏骱鬅o需維護即可投入使用，即具有分?jǐn)喽搪饭收虾蟮倪B續運行性能:CPS在進行了分?jǐn)喽搪冯娏髟囼灪?，仍具?000次以上的AC-44電壽命,這是由斷路器等分離器件構成的系統所難以達到的，CPS的這一特性極大地提高了系統的運行可靠性和系統的連續運行性能。

Compared with the system composed of the independent components

Automatic cooperation between control and protection

CPS integrates with control and protections, equivalent to the whole system composed of circuit breaker(fuse)+contactor+thermalrelay+auxiliary devices, well solve the coordination problem between control and protection what the system composed ofindependent components,is dificult to deal with.This protection and control cooperation is more perfect with inverse time limitdefinite time limit,and instantaneous three-stage protective characteristics,we can choose this single product only according toloading power or current, to sub-stitute the whole set of components from power incoming to load sides what shall be sued,it doesnot need to consider derating coecient, greatly reduce the job of technicians.

Excellent servicing reliability and continuity

After the CPS break short circuit current, it can put into operation again without maintenance, namely operation continuity after shorcircuit fault.After test of breaking short circuit current it still have more than 6000 cycles of electrical endurance at AC-44, which theseparate system is dificult to meet with, this performance can high improve the reliability and continuity of servicing, operating shortcircuit breaking capacity lcs up to 80kA, this keeps leadina all over the world and highest level in China
